John Deere AF13E Frontier™ Expandable Front Snow Blade
Features
Improve Productivity with the Expandable Snow Blade
Reduce the number of passes and pull snow from enclosed spaces, the AF13E Series Front Snow Blade makes quick work of snow-removal jobs. Using hydraulics to expand the blade horizontally, the AF13E blade has 6-to-10’ of working width, creating professional-grade results in less time.
Front-Mount Improves Capacity and Visibility
The AF13E Series Front Snow Blade comes equipped with a front blade lift system allowing the snow blade to articulate up to 10°. Providing increased capacity and functionality, over loader-mounted blades, the lift mounts directly onto the loader-mount locations and tractor frame. The hydraulics utilize the dual mid-SVC to expand and contract the blade, eliminating the need for third function and saving costs. Sitting close to the tractor frame operators will also have improved visibility to the snow blade and snow.
Hydraulics Designed for Cold Temperatures
Designed for ultra-low temperatures, the AF13E hydraulic hoses use ultra-low temperature resistant synthetic rubber.
Inverted Blade Removes Snow Up Close
Pull snow out of enclosed areas and away from objects with the inverted blade on the AF13E Expandable Front Snow Blade. The inverted blade has the capability to reach snow that other blades cannot such as, up close to buildings, garage doors, walls, and other enclosed structures.
TIVAR Cutting Edge
Helping to reduce harsh contact and surface markings, the tivar cutting edge that comes standard on the AF13E, is the ultimate choice for a range of surface types, including fragile ones such as paved stone.
Easy Serviceability
Communized cylinder components make serviceability easier than ever.
Key Specs
General
| Type | Inverted |
|---|---|
| Tractor HP Requirements (min.-max.) | 45-75 hp |
| Working Depth Control | Hydraulic |
Dimensions
| Width, Working MIN | 6ft 5in. (1955 mm) |
|---|---|
| Width, Working MAX | 10ft. 5in. (3175 mm) |
| Width, Overall MAX | 10ft. 8.13in (3254 mm) |
| Height, Overall | 56in. (1422mm) |
| Weight, Shipping | 2000 lbs. |
| Weight, Operating | 1680 lbs. |
| Height, Blade | 29in. (736.6mm) |
| Weight, Blade | 1147 lbs. |
| Depth, Blade | 27in. (685.8mm) |
| Weight, Hitch | 415 lbs. |
| Distance, To Ground lifted | 21in. (533.4mm) |
| Distance, Under the ground | 6in. (152.4mm) |
| Distance, Bumper to Cutting Edge | 24.5in (622.3mm) |
Cutting Edge
| Height, Cutting Edge | 5in. (127mm) |
|---|---|
| Thickness, Cutting Edge | 1in. (25.4mm) |
| Type | UHMW |
Skid Shoe
| Height, Skid Shoe Cutting Edge | 5in. (127mm) |
|---|---|
| Thickness, Skid Shoe Cutting Edge | 1in. (25.4mm) |
| Type, Skid Shoe | UHMW |
| Skid Shoe Adjustment | -2 @ 8 |
Frame
| Thickness, Frame (in.) | 1/4 |
|---|---|
| Harness Tube (in.) | 3 x 3 |
Extension Hydraulic Cylinder
| Double Hydraulic Cylinders | 3 x 24 |
|---|---|
| Flow Divider Block | Yes |
Lift Hydraulic Cylinder
| Double Hydraulic Cylinder | 2 x 10 |
|---|---|
| Ground Clearance (in.) | 20 |
