Code

Name

Description/Components/Compatibility

8492

Silage Preparation for M Series

• Supply as standard with MaxiCut HC rotor.
• Optional with RotoFlow HC rotor (see option code 1035).
• Dedicated chain/sprockets drive roll (roll #4).
• Improves belt traction in the event of slippage.

Code

Name

Description/Components/Compatibility

3900

Baler Automation – Select

• Compatible only with John Deere tractors equipped with ISOBUS and having Tractor Implement Automation (TIA) activation.
• The tractor must be equipped with Electronic Selective Control Valves (E-SCVs) and an Infinitely Variable Transmission (IVT) to operate all sub-modes:
• E-SCV: Gate cycle management
• IVT: Stop the tractor when the bale size is reached / enable tractor stop when pickup is plugged
• PTO disengagement

• Requires discharge ramp on baler (see option code 4020).
• Three Baler Automation sub-modes symbol with status on the main page (Red: Disabled / Green: Enabled / Blue: Active):
  • Gate Automation
  • Tractor Speed Automation
  • Unplug Assist Automation
• Automation widget included.
• Only on manual action, once gate is close and icon “Ready-to-Bale” appear on the display the operation will start again when the Command Pro joystick or reverser is cycled.
• No additional hydraulic SCV or Power Beyond system is needed.
• Manual bale unload function.
• Automation automatically disengages with a single touch on the SCV or brakes during operations.
• Each automation sub-modes can be disengaged if not required.

Code

Name

Description/Components/Compatibility

1049

MaxiCut HC68 Premium

• High-capacity design with large augers and rotor on the same axis.
• Three 6 mm (0.2 in.) thick high hardness steel double teeth per revolution.
• 2 set of knives (0-7-8-15), controlled from the display.
• Theoretical cutting length of 136 mm (5.3 in.) or 68 mm (2.7 in.).
• Hydraulic knives protection system with adjustable pressure.
• Knives position monitored from the cab.
• Full width drop floor, controlled from the display.
• Deliver with 15 knife filler plates and holder.

Code

Name

Description/Components/Compatibility

2101

Moisture Indicator

• Moisture indicator inside the bale chamber (right-hand side).
• Moisture values are displayed on two widgets:
• Instant value
• Last average moisture
• Crop type selection on moisture settings page for accurate measurements.
• Configurable moisture alarm on the moisture settings page.
• Function can be deactivated from the display.
• Moisture data is documented on the display or via the Operations Center.
• Yield map layer not available in the John Deere Operations Center (see option code 2102 for wrapper baler).
