AUGER

MORE REACH, HEIGHT & SPEED!

The Unverferth 60-Series of single auger grain carts feature a side-folding auger design that tucks in neatly along the side of the tank. This design allows the upper auger to be longer, equating to more side reach and greater height clearance and auger diameters up to 20” means faster unloading speeds!

ACCURATE UNLOADING

Unloading accuracy is optimized when the auger downspout is pointed straight down and the 60-series grain carts provide up to 9’ 9” of auger side reach and up to 13’ of auger height when in this position, reducing the risk of throwing grain off target.

AUGER FLIGHTING

Models 1160 and 1060 feature a 20" diameter auger for unloading speeds up to 500 bushels per minute and models 860 and 760 features an 18" diameter auger for unloading speeds up to 450 bushels per minute.

UNLOADING CONTROL

The standard two-way turret-style downspout is hydraulically controlled with 60 degrees of side-to-side rotation which adds unloading flexibility when filling semis.

An optional 4-way downspout is available and adds in-and-out movement for even greater operator control. This option requires one additional hydraulic remote on the tractor in addition to the standard 3 remotes required.

OPERATING CONVENIENCE

A fully visible auger fold position indicator allows the operator to monitor the auger during the entire folding process from inside the tractor cab.

TANK

TANK DESIGN

Models 1160, 1060, 860 and 760 feature tank capacities of 1,100, 1,000, 850 and 750 bushels to meet individual grower preferences.

HYDRAULIC FLOW GATE

Hydraulically operated 36" flow gate features a highly visible position indicator for easily controlling grain flow while unloading.

WEATHERGUARD ROLL-TARP

Model 1160 is standard with a weatherguard roll-over tarp to protect your harvested crop.

This same weatherguard roll tarp is optional on all other 60-Series models.

TANK STANDARD FEATURES

The 60-Series single auger grain carts feature a durable, high-grade enamel paint that is baked on in tractor red or green for a long-lasting and smooth, automotive-like finish and exposed seams are silicone sealed for corrosion resistance.

UNDERCARRIAGE

INDUSTRY-LEADING CHOICES

The 60-Series single auger grain cart lineup features industry-leading undercarriage options so you can choose the right undercarriage to meet your operation’s needs. Choose from high-flotation single wheels and tires, the 42” wide Equalizer® track system or a 36” wide traditional track system.

DURABILITY

All models feature a cast 2" single-tang hitch with a smooth chamfer opening and bushings that fit numerous hitch pin sizes, allowing the cart to trail smoothly.

HIGH-FLOTATION SINGLES

All models are available with a high-flotation single wheel and tire with various tire sizes available depending on the model and a rigid or adjustable axle depending on the tire size.

10-bolt hubs are manufactured from special alloy, high-strength steel with gusseted reinforcements for trouble-free operation.

36" WIDE TRACKS

The 36" wide track belt with 105” of ground contact length features a 4-bogie design and is available on the 1160 model. Models 1160 and 1060 can be equipped with a 2-bogie track with 87” of ground contact length.

40" end-wheels feature 10-bolt hubs that are greaseable with triple-lip seals and a steel guard for optimum lubrication. Purgeable grease hubs ensure the operator can “purge or push” out any dirt and debris from the hub, increasing the life and eliminating down time.

42" WIDE EQUALIZER TRACKS

The Equalizer track system has a patented design that features 8° of side-to-side camber and 20° of front-to-back pivot with independent movement of each track to provide uniform ground contact on uneven terrain. The standard auto-greaser system provides automatic application of grease at more frequent intervals for consistent lubrication.
