| Round bale diameter | Up to 5 ft 6 in (1,65 m) |
| Square bale | n/a |
| Bale type | Baleage/dry hay/straw |
| Specifications |
| Tandem axle | Standard |
| Tandem axle with brakes | Optional |
| Self-Steering axle with brakes | n/a |
| Safety chain | Standard |
| Self-loading arm design | Tubular round |
| Able to load a second row of bales | N/A |
| Tires | 400/60-22,5 |
| Caméra (de recul) | n/a |
| Tractor minimum hydraulic flow | 2200 psi (151 bar) |
| HP requirements | 100 HP |
| Tractor outlets required | 6 x 1/2" male quick couplers |
| PTO Speed/ PTO shaft | n/a |
| Controls | Tractor's hydraulic circuit |
| Dimensions |
| Width - A | 8 ft 5 in (2,6 m) |
| Overall width (inlcuding loading arm) | 9 ft 1 in (2,8 m) |
| Height - B | 7 ft 5 in (2,3 m) |
| Overall height (inlcuding loading arm) | 11 pi 1 po (3,38 m) |
| Bed height - E | 3 pi 9 po (1,1 m) |
| Overall length - D | 21 pi (6,4 m) |
| Overall weight | 7054 lb (3200 kg) |
| Empty Weight on tow bar*** | 1499 lb (680 kg) |
| Capacity |
| Round bale 4 ft x 4 ftdiameter (1,2 m x 1,2 m) | 10 |
| Round bale 4 ft x 5 ft diameter (1,2 m x 1,5 m) | 10 |
| Round bale 4 ft x 6 ft diameter (1,2 m x 1,8 m) | 10 |
| Round bale 5 ft x 5 ft diameter (1,5 m x 1,5 m) | 8 |
| Round bale 5 ft x 6 ft diameter (1,5 m x 1,8 m) | 8 |
| Square bale 3 ft x 3 ft x 8 ft long (90 cm x 90 cm x 2,4 m) | n/a |
| Square bale 4 ft x 3 ft x 8 ft long (1,2 m x 90 cm x 2,4 m) | n/a |
| Square bale 4 ft x 4 ft x 8 ft long (1,2 m x 1,2 m x 2,4 m) | n/a |
| Loading arm lifting capacity | 2500 lb (1135 kg) |
| Total weight including load | 29 800 lb (13 500 kg) |
