Meyer Farm Equipment SXR400
Features
- Pull Type Models in 4 sizes / Truck Mount Version available soon!
- Meyer patented straight-line flow - provides the ultimate spread performance. Better pattern, faster unload time, less horsepower & minimal wind drift!
- Rear Unload Rules! When it comes to spreading, keep the mess behind you. Provides superior application too.
- 3 auger system, only one of its kind! Lower 20" augers feed the door while the upper 13" auger levels the load forward and eliminates bridging.
- Thanks to the dual lower auger arrangement, the Meyer spreader body is wide down low. This means we can maintain a lower load height with maximum capacity! The other advantage is the near elimination of bridging which is common in side delivery spreaders.
- independent Lower Auger Shear Bolt Protection, a Meyer exclussive. Allows you to protect an obstructed auger while still unloading a majority of the load with the other auger. Bound to save you work!
- Heavy Duty Drivetrain - Crossfire models feature #120 final drive chains #80 expeller and first reduction. HD jackshafts / spring chain tensioning / remote greasing on hard to reach spots! The auto roller chain oiler is standard for added convenience and extended chain life.
- Automatic Roller Chain Oiler is standard. Oils all roller chains each time you cycle the tailgate. Eliminates reduced access and manure contamination associated with oil bath systems.
- Sectionally Flighted 20" Lower Augers propel material to the rear of the spreader. Full auger flighting / No Paddles to wrap, freeze or wedge material
- Our Revolutionary T-Post auger hold-down retains a nylatron (non maintenance) bushing and maintains tight auger tollerance to the tank floor. Provides you more complete cleanout!
- Vertical Twin Expellers pulverize material for smooth, even application. This machine bands material across the back like a ferilizer spreader would, unlike side delivery units that attempt to chuck all the product out one side. Paddles are replacable and reversible!
- Check out this Shock Load Coupler System....Drastically reduces "shock/stress" related to rocks and frozen material to your drivetrain. This dampening system combined with a torque disconnect clutch protect your expeller drive sytem.
- Direct shaft drive expellers (includes our shock load coupler). No chains on the rear of this spreader. V-Force models feature an overrunning clutch system to reduce backlash on the drivetrain.
- 540 CV PTO is standard - 1000 CV PTO is optional. Both incorporate a torque disconnect clutch to protect your investment.
- All Meyer spreaders feature a full channel frame. Stress from the hitch, axles and body are transmitted throught the frame network. Take a look at the unibody design on most V-Spreaders.
- Standard Hitch / Optional Hitch
The 7400 Model features a standard V-Hitch / the 7500 Model comes standard the long hitch package. (7500 pictured here with long hitch) - HD Axle System
This HD, offset A-Frame tandem on the V-Force models features 3" spindles on a 7500 (2 3/4" spindles on 7400) - both are 8 bolt. 10 bolt hub/spindle option available on 7500 model. - Many tire options available including rib implement tires and used truck tires.
- Angle splash shields standard front and rear on 7500; Elevated front splash shield and flat rear splash shield on 7400 model.
- LED turn signal lighting standard / Center Lift Door
The center lift door system eliminates arms and linkages - it is standard on the 7500 model - Hydraulic Lid Option
This Hydraulic Lid feature provides cleaner transportation and less odor pollution. Right or Left hinge available and a port hole is standard equipment. (7500 only) - Extension Package
This 4" side extension is available for the 7400. It increase it's capacity to 465 bushel or 2,150 gallons. - Scale Package
The 7500 Model is available with a 5 point scale package. Basic or Nutrient Tracker versions available.
