Built in the USA
Indicates products that are built in the United States from domestic and foreign parts and components.
Throttle Trigger Lock with Built-In Momentary Stop Switch
The built-in stop switch allows the user to turn off the engine with a simple press of the button or lever. When the engine is off, the throttle lock automatically returns to the “start” setting. Your power tool will be ready to be started when you’re ready to get back to work.
Purge Pump Primer
The purge pump primer feature enables the user to prime the carburetor with fuel, enabling easier starting. The purge pump primer is designed in a way that the operator cannot flood the machine by priming the carburetor too many times. Flooding the engine is still possible if the choke is not removed after the engine fires.
Multi-Function Control Handle
Having easy access to all of the controls on one comfortable handle makes it easy to complete tasks so the operator’s hand never has to leave the handle.
The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
The ElastoStart™ starter handle is an exclusive feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The ElastoStart™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
|BR 430 Specifications - Professional Use|
|DISPLACEMENT||63.3 cc (3.86 cu. in.)|
|ENGINE POWER||2.9 kW (3.9 bhp)|
|WEIGHT||10.1 kg (22.3 lbs.)|
|FUEL CAPACITY||1700 cc (57.5 oz.)|
|BLOWING FORCE*||26 Newtons|
|AVG. AIR VELOCITY**||82 m/sec. (183 mph)|
|MAX. AIR VELOCITY**||98 m/sec. (219 mph)|
|AIR VOLUME AT NOZZLE**||850 m3/h (500 cfm)|
|SOUND PRESSURE RATING**||76 dB(A)|
|*Newton is the force needed to accelerate 1 kg of mass at the rate of 1 m/sec².
**Tested in accordance with ANSI B175.2 standard.
All specifications provided by ANDREAS STIHL AG & Co. KG. As of April 2016.
