John Deere W61R

Double tap to zoom



Features

  • Compact design with a strong, welded frame for superior durability
  • V-twin engine delivers smooth operation and plenty of power
  • Self-propelled drive system gives infinite mowing speeds
  • Convenient controls for operator comfort and productivity
  • Thoughtful designs promote safe operation
  • Serviceability features and 2-year, bumper-to-bumper warranty maximize uptime
  • A fabricated floating mower deck delivers high-quality cut
  • Optional mulching attachment for extra convenience

Specifications

Key Specs

Engine manufacturer/model ECV740-EFI - California Air Resources Board (CARB) compliant
Engine power At 3600 rpm 25 hp*
18.6 kW
Fuel tank capacity 5.4 U.S. gal.
20.4 L
Mower deck Size 61 in.
155 cm
Blade tip speed Approximately 18,000 fpm
5,486 m/min
Transmission Two Hydro-Gear™, 0.73-cu in. (10-cc) hydraulic pumps and Danfoss 12 cu-in. (197-cc) wheel motors and ergonomic handles with spring loaded neutral lock
Speed range Forward, 0-7.5 mph
0-12.1 km/h
Reverse, 0-3 mph
0-4.8 km/h
Drive wheels 18x8.5-8
Caster wheels 9x3.5-4 semi-pneumatic
Warranty 24 month, single source commercial

Engine

Manufacturer/model ECV740-EFI - California Air Resources Board (CARB) compliant
Power At 3600 rpm 25 hp*
18.6 kW
Displacement 45.6 cu in.
747 cc
Cylinders V-twin
Crankcase capacity
Operating speed 3,600 rpm
Idle Speed
Ignition/Starter Electronic/electric start
Valving Overhead valves
Oil filter Standard
Lubrication Full pressure
Governor Flyweight all speed governor
Hourmeter Standard, digital
Cooling system Air cooled
Air cleaner Dual HD canister
Muffler Low tone

Fuel System

Fuel type Gasoline
Fuel tank capacity 5.4 U.S. gal.
20.4 L
Fuel pump Vacuum-operated diaphragm
Fuel delivery system Closed-loop electronic fuel injection (EFI)
Fuel tank switch/Shut off valve No
Filler neck opening
Fuel pickup Top draw

Electrical System

Ignition Electronic spark
Hourmeter Standard, digital
Operator presence starting system PTO off, park brake engaged, speed lever in neutral

Drivetrain

Transmission Two Hydro-Gear, 0.73-cu in. (10-cc) hydraulic pumps and Danfoss 12 cu-in. (197-cc) wheel motors and ergonomic handles with spring loaded neutral lock
Wheel motors Danfoss 12 cu in.
197 cc
Shift mechanism Ergonomic handles with spring-loaded neutral lock

Tires

Drive wheels 18x8.5-8
Outside to outside tire measurement
Caster wheels 9x3.5-4 semi-pneumatic
Shift mechanism

Travel Speed

Forward speeds Infinite
Reverse speeds Infinite
Speed range Forward, 0-7.5 mph
0-12.1 km/h
Reverse, 0-3 mph
0-4.8 km/h

Brakes

Type Dynamic braking with hand controls, hand lever to set parking brake

Dimensions

Height 44.8 in.
114 cm
Length with deck 83 in.
211 cm
Width Deflector down - 75 in.
191 cm
Deflector up for storage - 65 in.
165 cm
Weight 745 lb
338 kg

Mower Decks

Size Material
10-gauge, 0.14-in. (3.42-mm) fabricated steel deck top with added 10-gauge, 0.14-in. (3.42-mm) spindle mounting plate, 7-gauge, 0.19-in. (4.8-mm) side skirts with reinforcement bar
Blades
Three high-lift
Length - 21 in.
53.3 cm
Thickness - 0.25 in.
0.64 cm
Blade drive
V-Belt
Blade tip speed
Approximately 18,000 fpm
5,486 m/min
Cutting height
1.5-4.5 in.
3.8-11.4 cm

61 in.
155 cm
