John Deere BL7B Snow/Utility Blade
Snow Attachments BL7B Snow/Utility Blade
Overview:
• Weight: 461 kg (1016 lb.)
• Angled Width: 1829 mm (72 in.)
• Width: 2134 mm (84 in.)
Share This Product:
Features
- Worksite Pro snow/utility blades provide additional productivity in snow removal and light dirt work.
- Blade angles hydraulically 30 degrees , right, or left. Adjustable skid shoes are standard.
- Blade oscillates 5 degrees, right or left.
- Four trip springs help protect the vehicle from sudden impacts with obstacles when blading snow. Trip springs can be locked out for light grading and dirt work.
- Bolt-on replaceable 152-mm (6- in.) edge is 13-mm (0.5 in.) thick. Available rubber cutting edges prevent damage to decorative surfaces.
- Blade height is 711 mm (28 in.); an 203-mm (8 in.) full-length extensions available.
Specifications
| Model | BL7B Snow/Utility Blade |
| Width | 2134 mm (84 in.) |
| Angled Width | 1829 mm (72 in.) |
| Height | 711 mm (28-in.) |
| Weight | 461 kg (1016 lb.) |
| Vehicle Compatibility | 313, 315, 318, 320D, 326D, 328D, and 332D Skid Steers; CT315, 319D, 323D, 329D, and 333D Compact Track Loader; and 110 Tractor Loader Backhoe |
