John Deere RR84 Root Rake
Rakes & Tillers RR84 Root Rake
Overview:
• Overall Width: 84 in. (2135 mm)
• Time Spacing: 8.5 in. (215 mm)
• Weight: 1,220 lb. (553 kg)
Share This Product:
Features
- Designed specifically for land clearing, ground leveling, and moving materials away from buildings and obstructions more quickly and economically than dozer blades.
- Handily gather rocks and debris while allowing soil to sift through, for minimal site and landscape disturbance.
- Alloy-steel construction, replaceable pin-on teeth, and zinc-plated greaseable pivot pins with protected zerks and hardened-steel bushings ruggedly resist impact.
- Attachment height and width help shield the front of the machine against large piles of brush and jagged scrap.
- Weld-on "D" ring enables the tackling of a wide variety of jobsite tasks.
Specifications
| Model | RR84 |
| Overall Width | 84 in. (2135 mm) |
| Overall Height | 38.9 in. (990 mm) |
| Overall Length | 30.8 in. (780 mm) |
| Grapple | |
| Width | 70 in. (1780 mm) |
| Opening | 51 in. (1295 mm) |
| Tooth Position | 25 in. (635 mm) |
| Tine Spacing | 8.5 in. (215 mm) |
| Weight | 1,220 lb. (553 kg) |
| Cylinder | |
| Bore | 2.5 in. (65 mm) |
| Stroke | 9 in. (230 mm) |
| Rod Diameter | 1.5 in. (40 mm) |
| Vehicle Compatibility | 330G and 332G Skid Steers; 323E, 331G, and 333G CTLs; and 204K, 244K, 304K, 324K, and 344K Compact Wheel Loaders |
