John Deere RC78B Rotary Cutter
Cutters, Shredders & Mulchers RC78B Rotary Cutter
Overview:
Cutting Width: 1981 mm (78 in.)
Overall Length: 2388 mm (94 in.)
Weight: 617 kg (1,360 lb.)
Cutting Capacity: 102 mm (4 in.)
Share This Product:
Features
- Redesigned direct drivetrain eliminates the gearbox, for improved performance, durability, and reliability.
- Triple bidirectional blade design of 19.1-mm (0.75)-thick high-grade steel helps stabilize balance, for smooth operation and increased cutting efficiency.
- Optional new pressure gauge is highly visible, allowing easy monitoring of blade capacities to prevent overheating and overloading.
- Optional new under-mounted front steel wheels provide even cuts, extend blade wear life by keeping it off the ground, and prevent scalping.
Specifications
| Model | RC78B |
| Overall height | 610 mm (24 in.) |
| Overall length | 2388 mm (94 in.) |
| Overall width | 2083 mm (82 in.) |
| Weight | 617 kg (1,360 lb.) |
| Minimum cutting height | 51 mm (2 in.) |
| Cutting width | 1981 mm (78 in.) |
| Cutting capacity | 102 mm (4 in.) |
| Recommended output | 57-95 L/m (15-25 pgm) |
| Flow | Standard |
| Required skid steer lift capacity | 680 kg (1,500 lb.) |
| Vehicle compatibility | 326E/E, 328D/E, and 332D/E Skid Steers; 329D/E and 333D/E CTLs |
| Required parts * | Sever-duty door (includes windshield wiper); severe-duty door hardware kit (for use with ROPS canopy units only- not required for cab units) |
| Optional kits | |
| Pressure gauge | |
| Front Wheels: | |
| Weight | 30 kg (66 lb.) |
| *Required to meet ISO 8084 Forestry Applications. | |
