John Deere GT72 Brush-Tined Grapples
Double tap to zoom
- Each unit includes two independent-action grapples that allow different-sized objects to be grasped and retained.
- Grapple opening of 971 mm (38.2 in.) allows large payloads.
- 100-mm (4-in.) tine spacing works well for sorting or sifting materials.
|Model||GT72 Brush-Tined Grapples|
|Width||71.5 in. (1816 mm)|
|Length||39.0 in. (990mm)|
|Height (Grapple Closed)||28.5 in. (724 mm)|
|Height (Grapple Opened)||45.9 in. (1167mm)|
|Grapple Opening||38.2 in. (971 mm)|
|Number of Tines||16|
|Tine Spacing (Opening between tines)||4 in. (100 mm)|
|Operating Weight||955 lb. (434 kg)|
|Vehicle Compatibility||312GR, 314G, 316GR, 318G, 320E, 324E, and 330G Skid Steers; 317G and 323E Compact Track Loaders; and 204K, 244K, 304K, and 324K Compact Loaders|
