John Deere RC72B Rotary Cutter
Double tap to zoom
- Redesigned direct drivetrain eliminates the gearbox, for improved performance, durability, and reliability.
- Triple bidirectional blade design of 19.1-mm (0.75)-thick high-grade steel helps stabilize balance, for smooth operation and increased cutting efficiency.
- Optional new pressure gauge is highly visible, allowing easy monitoring of blade capacities to prevent overheating and overloading.
- Optional new under-mounted front steel wheels provide even cuts, extend blade wear life by keeping it off the ground, and prevent scalping.
|Overall height||610 mm (24 in.)|
|Overall length||2235 mm (88 in.)|
|Overall width||1930 mm (76 in.)|
|Weight||581 kg (1,280 lb)|
|Minimum cutting height||51 mm (2 in.)|
|Cutting width||1829 mm (72 in.)|
|Cutting capacity||102 mm (4 in.)|
|Recommended output||57-95 L/m (15-25 pgm)|
|Required skid steer lift capacity||635 kg (1,400 lb.)|
|Vehicle compatibility||315, 318D/E, 320E/E, 326D/E,
328D/E, and 332D/E Skid Steers;
319D/E, 323D/E, 329D/E, and
|Required parts *||Sever-duty door (includes windshield wiper); severe-duty door hardware kit (for use with ROPS canopy units only-
not required for cab units)
|Weight||30 kg (66 lb.)|
|*Required to meet ISO 8084 Forestry Applications.|
