John Deere DH1066

DH1066 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Double tap to zoom



Features

  • Sealed bearings increases life
  • Notched blades aggressively cut and mulch soil
  • Disk gangs adjust to match soil conditions
  • iMatch™ compatible for quick connection

Specifications

Dimensions

Working width 1.2 m
4 ft

Weight

Operating 176 kg
388 lb
Shipping 205 kg
452 lb

Tractor requirements

Horsepower range Max: 20.9 kW
28 hp

Hitch

Type Integral
Category Cat. 1

Blade

Spacing Front
19.1 cm
7.5 in.
Rear
19.1 cm
7.5 in.
Size 40.6 cm
16 in.
Thickness 3 mm
0.1181 in.
Quantity 12
Type Notched (front) / Notched (rear)
Standard

Gang axle

Diameter 25.4 mm
1 in.
Type Square
Material Steel

Gang angles

Front 2, 6, 12, 18 degree (angle)
Rear 10, 14, 18, 23 degree (angle)

Tubing

Frame 50.8x50.8x3 mm
2x2x0.1196 in.
50.8x50.8x4.8 mm
2x2x0.1875 in.
Gang 50.8x50.8x4.8 mm
2x2x0.1875 in.

Bearing hanger

Material Formed steel plate
Size 9.5 mm
0.375 in.
U-bolt size 12.7 mm
0.5 in.
Bearing type Self-aligning sealed ball bearing in pre-rivited flange

Set-up time

Labor hours 0.25

Warranty

Time period 1 year
