John Deere DH1048

DH1048 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Double tap to zoom



Features

  • Sealed bearings increase life
  • Notched blades aggressively cut and mulch soil
  • Disk gangs adjust to match soil conditions
  • iMatch™ compatible for quick connection

Specifications

Model  John Deere DH1048 Series Disk Harrow
DIMENSIONS
Working width 1.2 m
4 ft
WEIGHT
Operating 176 kg
388 lb
Shipping 205 kg
452 lb
TRACTOR REQUIREMENTS
Horsepower range  (10.4-20.9 kW)
14-28 hp
HITCH
Type Integral
Category  3-Pt./Cat.1
BLADE
Spacing Front
19.1 cm
7.5 in.Rear
19.1 cm
7.5 in.
Size 40.6 cm
16 in.
Thickness 3 mm
0.1181 in.
Quantity 12
Type Notched (front) / Notched (rear)
Standard
GANG AXLE
Diameter 25.4 mm
1 in.
Type Square
Material Steel
GANG ANGLES
Front 2, 6, 12, 18 degree (angle)
Rear 10, 14, 18, 23 degree (angle)
TUBING
Frame 50.8x50.8x3 mm
2x2x0.1196 in.
50.8x50.8x4.8 mm
2x2x0.1875 in.
Gang 50.8x50.8x4.8 mm
2x2x0.1875 in.
BEARING HANGER
Material Formed steel plate
Size 9.5 mm
0.375 in.
U-bolt size 12.7 mm
0.5 in.
Bearing type Self-aligning sealed ball bearing in pre-rivited flange
SET-UP TIME
Labor hours 0.25
WARRANTY
Time period 1 year
