John Deere 2210 Level-Lift

John Deere 2210 Level-Lift for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Seedbed Tillage



  • Variety of frame models and working widths
  • Guide to transport dimensions
  • Compatible with other crop production equipment
  • Offer excellent residue-handling capabilities
Manufacturer John Deere
Model 2210 Level-Lift
Fold
Type  3-section, 3-section low transport
Working widths
Rigid frame  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
Rigid over-center fold  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
3-section  ---
Option 1  20, 6 to 28, 6 (10, 0 mainframe) ft, in.
Option 2  23, 6 to 38, 6 (12, 0 mainframe) ft, in.
Option 3  34, 6 to 38, 6 (15, 0 mainframe) ft, in.
Option 4  40, 1 to 45, 7 (15, 0 mainframe with low transport option) ft, in.
Option 5  ---
Option 6  ---
5-section  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
Transport width
Rigid frame  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
3-section  ---
Option 1  14, 4 (10, 0 mainframe) ft, in.
Option 2  16, 5 (12, 0 mainframe) ft, in.
Option 3  19, 5 (15, 0 mainframe) ft, in.
Option 4  19, 5 (15, 0 mainframe with low transport option) ft, in.
Option 5  ---
Option 6  ---
5-section  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
Transport height
Rigid frame  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
Rigid over-center fold  ---
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
3-section  ---
Option 1  10, 4 to 13, 8 (10, 0 mainframe) ft, in.
Option 2  10, 4 to 17, 7 (12, 0 mainframe) ft, in.
Option 3  14, 3 to 15, 8 (15, 0 mainframe) ft, in.
Option 4  14, 3 (15, 0 mainframe with low transport option) ft, in.
Option 5  ---
Option 6  ---
5-section  ---
Option 1  ---
Option 2  ---
Option 3  ---
Operating depth
Inches  to 5 in.
Operating speed
Miles per hour  5 to 8 mph
Horsepower required
Horsepower per foot  4-8 PTO hp/ft. (200 lb. shanks may require 1-2 more hp/ft.)
Depth control
Option 1  Single Point
Option 2  TouchSet
Option 3  ---
Hydraulic requirements
Standard  2 SCVs (lift and fold) at 2500 psi for optimum raise times
Option 1  ---
Option 2  ---
Electrical requirements
Standard  9-pin connector for warning lights
Option 1  ---
Option 2  ---
Hitch
Type  T-hitch
Frame
Tubing  4 x 4-in. high-strength, box beam steel cross tubes through 3X6-in. and 2X5-in. steel fore-aft tubes (patented Tube-Thru-Tube design), welded construction
Number of ranks  5
Fore-and-aft  134 in.
Underframe clearance  24 in.
Standard spacing
Inches  4.5, 6, 9 in.
Standard options
Option 1  Tru-Position C-Shank
Spec  5/8 X 1-3/4 in.
Trip force  150 lb
Trip height  10 in.
Maximum operating depth  5 in.
Underframe clearance  24 in.
Spacing  6, 9 in.
Option 2  Tru-Position C-Shank
Spec  3/4 X 1-3/4 in.
Trip force  200 lb
Trip height  10 in.
Maximum operating depth  5 in.
Underframe clearance  24 in.
Spacing  6, 9 in.
Option 3  S-tine
Spec  1/2 X 1-3/4 in.
Trip force  ---
Trip height  ---
Maximum operating depth  ---
Underframe clearance  24 in.
Spacing  4 1/2 in.
Option 4  ---
Spec  ---
Trip force  ---
Trip height  ---
Maximum operating depth  ---
Underframe clearance  ---
Spacing  ---
Ground-engaging components
Options  Wide variety of sweeps, shovels, and points
Centerframe depth control wheels and tires
Option 1  Walk-Over Tandems (4) 11L-15FI load range D tires:
   6.25 to 11.77 m
   20.5 to 38.6 ft
Option 2  Walk-Over Tandems (4) 11L-15FI load range F tires (40-ft. 6-in. through 45-ft. 7-in.)
   12.34 to 13.9 m
   40.5 to 45.6 ft
Option 3  ---
Option 4  ---
Option 5  ---
Wing frame wheels and tires
Option 1  Walk-Over Tandems (4) 11L-15Fl load range D tires:
   6.25 to 11.73 m
   20.5 to 38.5 ft
Option 2  Walk-Over Tandems (4) 11L-15Fl load range F tires:
   12.57 to 13.87 m
   41.25 to 45.5 ft
Option 3  ---
Option 4  ---
Stabilizer wheels
Option 1  (2) 9.5L-15FI tires on front stabilizer wheels (low transport models)
Option 2  ---
Option 3  ---
Option 4  ---
Option 5  ---
Spike tooth harrow
Option 1  5-bar spike-tooth harrow
Rank spacing  ---
Spike spacing  10 in.
Effective spacing  2 in.
Spike dimension  .75 x .75 x 10 in.
Angle  30 or 45 degree (angle)
Adjustments  angle
Option 2  ---
Rank spacing  ---
Spike spacing  ---
Effective spacing  ---
Spike dimension  ---
Angle  ---
Adjustments  ---
Option 3  ---
Rank spacing  ---
Spike spacing  ---
Effective spacing  ---
Spike dimension  ---
Angle  ---
Adjustments  ---
Coil tine harrow
Option 1  3-bar coil-tine harrow
Rank spacing  12 in.
Tine spacing  9 in.
Effective spacing  3 in.
Tine dimensions  .438 x 16 in.
Angle  6 choices from aggressive to shallow
Adjustments  down pressure, height (no soil engagement option), pitch, and angle adjustment
Option 2  4-bar coil-tine harrow
Rank spacing  12 in.
Tine spacing  9 in.
Effective spacing  2.25 in.
Tine dimensions  .438 x 16 in.
Angle  6 choices from aggressive to shallow
Adjustments  down pressure, height (no soil engagement option), pitch, and angle adjustment
Option 3  ---
Rank spacing  ---
Tine spacing  ---
Effective spacing  ---
Tine dimensions  ---
Angle  ---
Adjustments  ---
Rolling basket harrow
Option 1  2-bar coil tine harrow with rolling basket
Spike/tine  2-bars of coil tines
Rank spacing  12 in.
Spike/tine spacing  9 in.
Effective spacing  4.5 in.
Spike/tine dimensions  .438 x 16 in.
Basket  no center shaft
Basket diameter  14 in.
Bar type  spiraling rods
Bar size  .875 in.
Bearings  Dura-Flex (3+1) bearings eliminate the need for gang bolt, spacers, washer, and wide bearings and mounts
Adjustments  tine tooth angle, basket down pressure
Option 2  3-bar spike with rolling basket
Spike/tine  3-bar spike
Rank spacing  ---
Spike/tine spacing  10 in.
Effective spacing  3.33 in.
Spike/tine dimensions  .75 x .75 x 10 in.
Basket  spiral arrangement
Basket diameter  11 in.
Bar type  flat bar
Bar size  ---
Bearings  Dura-Flex bearings with triple-lip seals on the inner race plus a wide seal between the bearing and flange. The bearings are self-aligning and greaseable for longer life.
Adjustments  30 or 45 spike degree and 4 positions for basket down pressure
Option 3  ---
Spike/tine  ---
Rank spacing  ---
Spike/tine spacing  ---
Effective spacing  ---
Spike/tine dimensions  ---
Basket  ---
Basket diameter  ---
Bar type  ---
Bar size  ---
Bearings  ---
Adjustments  ---
Rear hitch
Description  ---
Tubing size  ---
Telescoping  yes
Tongue weight rating  1000 lb
SS  6500 lb
Wiring harness for transport lights  ---
Hydraulic hoses and couplers  one set
Warranty
Description  3-year frame and standard warranty
Additional feature
Option 1  ---
Option 2  ---
Option 3  ---
Option 4  ---
Option 5  ---
