John Deere DH5414
Frontier Heavy Offset Disks DH5414
Share This Product:
Features
- Adjustable disk blade scrapers increase productivity
- End washers and wrenches keep gang shaft end nut tight
- Transport locks secure disk wings
- Two separate control arms create consistent performance
- Oil bath tapered roller bearings minimize maintenance
Specifications
Transport
| Width | 4.6 m 15 ft |
| Wheel hub bearings | Dual tapered roller bearings |
Working
| Approximate working width | 4.3 m 14 ft |
Weight
| Net | 5942.1 kg 13100 lb |
| Weight per disk blade | 228.2 kg 503 lb |
Tractor requirements
| Recommended drawbar hp range | 223.7 kW 300+ hp |
Frame
| Type | Single offset rigid |
| Duty | Heavy |
| Tube size | 17.8x17.8x0.95 cm 7x7x0.375 in. |
Hitch
| Front hitch type | Pintle |
Disk blades
| Spacing | 33 cm 13 in. |
| Quantity | 26 |
| Type | Notched (front) Notched (rear) Standard |
Available blade sizes
| Blade option one | 762x12.7 mm 30x0.5 in. |
| Blade option two | 813x12.7 mm 32x0.5 in. |
Disk gangs
| Front angle | 3 positions |
| Rear angle | 3 positions |
| Axle material | Round heat treated alloy steel threaded on both ends |
| Bearing type | Oil bath tapered roller |
| Bearing wear plates | Standard |
| Bearing standards | Welded, Reinforced |
| Scrapers | Adjustable |
Lighting and safety
| Markings | SMV |
| Safety tow chain | Yes |
| Lights | Yes |
Tires
| Type | 2 - Radial industrial |
| Size | 385/65R22.5 |
| Wheel hub type | 5-Spoke dayton hubs |
Set-up time
| Labor hours | 2-3 for two people |
Warranty
| Time period | 1 year |
