John Deere DH5411

Double tap to zoom



Features

  • Adjustable disk blade scrapers increase productivity
  • End washers and wrenches keep gang shaft end nut tight
  • Transport locks secure disk wings
  • Two separate control arms create consistent performance
  • Oil bath tapered roller bearings minimize maintenance

Specifications

Transport

Width 4.6 m
15 ft
Wheel hub bearings Dual tapered roller bearings

Working

Approximate working width 4.3 m
14 ft

Weight

Net 5942.1 kg
13100 lb
Weight per disk blade 228.2 kg
503 lb

Tractor requirements

Recommended drawbar hp range 223.7 kW
300+ hp

Frame

Type Single offset rigid
Duty Heavy
Tube size 17.8x17.8x0.95 cm
7x7x0.375 in.

Hitch

Front hitch type Pintle

Disk blades

Spacing 33 cm
13 in.
Quantity 26
Type Notched (front) Notched (rear)
Standard

Available blade sizes

Blade option one 762x12.7 mm
30x0.5 in.
Blade option two 813x12.7 mm
32x0.5 in.

Disk gangs

Front angle 3 positions
Rear angle 3 positions
Axle material Round heat treated alloy steel threaded on both ends
Bearing type Oil bath tapered roller
Bearing wear plates Standard
Bearing standards Welded, Reinforced
Scrapers Adjustable

Lighting and safety

Markings SMV
Safety tow chain Yes
Lights Yes

Tires

Type 2 - Radial industrial
Size 385/65R22.5
Wheel hub type 5-Spoke dayton hubs

Set-up time

Labor hours 2-3 for two people

Warranty

Time period 1 year

Additional information
