John Deere 1735

Double tap to zoom



Features

  • SeedStar™ 2 monitoring system gives integrated innovation
  • Seed variable-rate drive provides the ultimate planting productivity
  • Pneumatic downforce system
  • Advance with MaxEmerge™ 5 advantages
  • Ground-contact drive wheel
  • Vacuum system
  • John Deere Connected Support™ prevents downtime and efficiently resolves issues with revolutionary technology-based solutions

Specifications

Key Specs

Number of rows 11, 12, 15
Row spacing 11 Row: 38 cm
15 in.
11 Row: 46, 48, and 51 cm
18, 19, and 20 in.
12 Row: 56 cm
22 in.
15 Row: 38 cm
15 Row: 46, 48, and 51 cm
Row unit seed hoppers Capacity
58 or 106 L
1.6 or 3 bu
Seed Meters Base
Vacuum

Rows and Row Spacing

Number of rows 11, 12, 15
Row spacing 11 Row: 38 cm
15 in.
11 Row: 46, 48, and 51 cm
18, 19, and 20 in.
12 Row: 56 in.
22 in.
15 Row: 38 cm
15 Row: 46, 48, and 51 cm

Lift System

Type Integral or Semi-integral

Tires

Base 7.60-15 6 Ply - Traction: 280 kPa
2.8 bar (40 psi)
7.60-15 8 Ply - Traction: 359 kPa
3.6 bar (52 psi)

Row Units

Type MaxEmerge™ 5 row unit
Opener Tru-Vee Double Disk
Row unit seed hoppers Capacity
58 or 106 L
1.6 or 3 bu
Seed tube sensors Optional
--

Seed Meters

Base Vacuum

Drive System

Base Ground driven or hydraulic driven

Markers

Type Automatic alternating or independent control

Dimensions

Transport width (with markers) 6 Row Narrow: 4978 mm
196 in.
6 Row Wide: 7036 mm
277 in.
6 Row Narrow: 7036 mm
12 Row 55 cm (22 in.): 8839 mm
348 in.
Transport width (without markers) 6 Row Narrow: 4572 mm
180 in.
6 Row WIde: 5842 mm
230 in.
6 Row Narrow: 5842 mm
6 Row Wide: 5842 mm
12 Row 55 cm (22 in.): 7620 mm
300 in.
Transport length 6 Row Narrow: 4115 mm
162 in.
6 Row Wide: 4115 mm
12 Row 55 cm (22 in.): 4115 mm
Transport weight 11 Row Narrow: 1350 kg
2975 lb
11 Row Wide: 1490 kg
3280 lb
12 Row: 2290 kg
5050 lb
15 Row Narrow: 1680 kg
3700 lb
15 Row Wide: 1790 kg
3950 lb

Additional Information

Recommended tractor hydraulics Hydraulic oil required to operate the planter: 5.7 L
1.5 gal.
Hydraulic system working pressure: 20,684 kPa
207 bar (3000 psi)
Hydraulic system burst pressure: 82,737 kPa
827 bar (12,000 psi)
