John Deere 1795 24Row20

Double tap to zoom



Features

  • Precise liquid fertilizer placement with ExactRate™ fertilizer system
  • Increase productivity with ExactEmerge™ trench delivery system and BrushBelt™ delivery system
  • Dual 56-V electric motors for ExactEmerge™ row-units
  • SeedStar™ 4HP monitoring system – see speed meet accuracy in real time
  • Increase job performance when planting and spraying
  • Mobile row-unit runoff
  • Downforce system options
  • Pneumatic closing wheels
  • Easy Adjust row cleaners
  • Achieve accuracy with Curve Compensation
  • John Deere Connected Support™ prevents downtime and efficiently resolves issues with revolutionary technology-based solutions

Specifications

Key Specs
Number of rows 20
Row spacing 24R20: 51 cm
20 in.
Frame - Fold configuration
Frame - Flexibility Up and down: 15 degree (angle)
Row unit seed hoppers Capacity
Vacuum meter: 2.2 L
0.62 bu
Seed Meters Base
Vacuum

Rows and Row Spacing
Number of rows 24
Row spacing 24R20: 51 cm
20 in.
Frame
Flexibility UP and down: 15 degree (angle)
Lift System
Type Wheel modules with rephasing hydraulic cylinders
Tires
Base Fertilizer contact drive tire: 18x9.56-8 4PR: 193 kPa
1.93 bar (28 psi)
Center frame tires (4 per machine): 31R15,32R15, 24R20, 23R15and 24R15 with fertilizer: 11R22.5 TL LR F: 414 kPa
4.14 bar (60 psi)
Wing tires (4 per machine): 7.50-20 6 Ply: 248 kPa
2.48 bar (40 psi)
Row Units
Type Standard: MaxEmerge™ 5 row units
Optional: ExactEmerge™ row units
Opener Tru-Vee Double Disk
Row unit seed hoppers Capacity
Vacuum meter: 2.2 L
0.063 bu
Seed Meters
Base Vacuum
Drive System
Base 56 V Electric motors
Markers
Type Automatic alternating or independent control
Seed Monitor System
Base SeedStar™ on GreenStar™ displays
Dimensions
Transport width (with markers) 24R20: 4.77 m
14.67 ft
Transport length 24R20: 10.46 m
34.33 ft
Transport height 24R20: 3.96 m
13 ft
Field operation width 24R20: 13.2 m
43.37 ft
Field operation length 24R20: 7.7 m
25.34 ft
Additional Information
Recommended tractor horsepower Minimum required for 9.1 m (30 ft) models: 201 kW
270 hp
Minimum required for 12.2 m (40 ft) models: 268 kW
360 hp
Recommended tractor hydraulics Hydraulic oil pump required to operate ExactEmerge™ planter: 227 L/min
60 gpm
Tractor standby pressure: 15,500 kPa
155 bar (2300 psi)
Hydraulic system working pressure: 20,684 kPa
207 bar (3000 psi)
Hydraulic system burst pressure: 82,737 kPa
827 bar (12,000 psi)
