John Deere 530D

Double tap to zoom



Features

  • Interchangeable with John Deere rotary platforms
  • Higher productivity with center-driven belts
  • Strong, positive-feeding reel handles all crop conditions
  • John Deere parts and service support provide uptime for a timely harvest
  • Draper hydraulic pump control logic delivers constant header speed
  • Hydraulic deck shift (double swath package)



Specifications

Key Specs

Cutterbar - Type SCH® Easy Cut with roller guides, spring steep guards, and bolted sections
Standard: single knife
Optional: dual knife
Cut width (length) 9.1 m
30 ft
Reel type Hydraulic
Fingers Plastic
Belt width V-guided draper belt: 106.7 cm
42 in.
Transport length, hitch extended 10.5 m
34.6 ft

Cutterbar

Type SCH® Easy Cut with roller guides, spring steep guards, and bolted sections
Standard: single knife
Optional: dual knife
Cut width (length) 9.1 m
30 ft
Knife drive Two hydraulic motors and two knife drives
Knife speed 1,100 to 1,440 spm
Stroke length 84 mm
3.3 in.
Cutterbar tilt Hydraulic, adjustable from cab

Reel

Reel type Hydraulic
Number of bats Six
Fingers Plastic
Diameter 1118 mm
44 in.
Height control Hydraulic, adjustable from cab
Speed control Hydro handle, in cab
Reel lift Hydraulic, adjustable from cab
Reel fore and aft Hydraulic, adjustable from cab

Draper and decks

Belt width V-guided draper belt: 106.7 cm
42 in.
Delivery opening width Delivery, double swath opening: 137.2 cm
54 in.
Delivery, single swath opening: 203.2 cm
80 in.
Delivery opening height 205.7 cm
81 in.
Draper drive Two hydraulic motors
Operating speed 0 to 232 m/min
0 to 760 fpm
Speed control Adjustable in windrower cab
Remote canvas speed control Standard
Deck tilt Standard
Deck extensions Optional, dealer-installed deck extensions: 35.6 cm
14 in.

Auxiliary top auger

Type Optional: factory-installed cross-pea auger

Dimensions

Operating width (field) 9.1 m
30 ft
Transport width (reel fully retracted) 2.6 m
8.5 ft
Transport height 2.44 m
8 ft
Transport length, hitch extended 10.5 m
34.6 ft

Weight

Approximate weight (base platform without reel) 1232 kg
3513 lb
Approximate weight (base platform with reel) 2710 kg
5975 lb

Gauge wheels and transportation

Gauge wheels Adjustable castoring gauge wheel optional
Integrated slow speed transport system Self-contained transport, including hitch, jack and axle, is conveniently stored on the swather table
