John Deere 1435D

Double tap to zoom



Features

  • Cutterbar and frame profile gives uninterrupted crop flow
  • Strong, positive-feeding reel handles all crop conditions
  • Excellent visibility to cutterbar and belt
  • Gauge wheels provide ground following for uniform cut
  • Hydraulic deck shift gives larger windrows for more efficient harvesting
  • Transport easily with integrated transport system

Specifications

Key Specs

Cutterbar - Type Dual knife base standard
Single knife base optional
Cut width (length) 10.7 m
35 ft
Reel type Pick up cam 4 position adjustable release
Fingers Heavy-duty plastic
Belt width Wide rubber skim-coated 710-ml (24-oz) drapers: 1,259 mm
49.6 hp/ft
Platform length 11.1 m
36.3 ft
Overall operating depth With crop dividers 2.6 m
8.7 ft
Transport width, field position 11.1 m
36.3 ft
Transport width on wheel, less dividers 2.5 m
8.1 ft
Transport length, hitch extended 13.9 m
45.6 ft

Cutterbar

Type Dual knife base standard
Single knife base optional
Cut width (length) 10.7 m
35 ft
Knife drive Hydraulic motor to belt to enclosed heavy-duty wobble box
Knife speed Dual: 600-750 cycles/min
1,200-1,500 spm
Single: 550-650 cycles/min
1,100-1,300 spm
Stroke length
Cutterbar tilt Standard hydraulic
Optional mechanical (2.5-12.0 degree tilt)

Reel

Reel type Pick up cam 4 position adjustable release
Number of bats 5 bats single span standard
6 bats split span optional, capped ends
Fingers Heavy-duty plastic
Diameter 1,650 mm
65 in.
Height control Hydraulic
Speed control Hydraulic with header index
Reel lift Hydraulic
Reel fore and aft Hydraulic
Operating speeds 0-85 rpm

Draper and decks

Belt width Wide rubber skim-coated 710-ml (24-oz) drapers: 1,259 mm
49.6 in.
Operating speed 0-225 m/min
0-742 fpm
Speed control Hydraulic from cab

Header height sensing

Type
Header height sensing on the ground Float springs on traction unit
Header height sensing off the ground Return to cut height standard
Gauge wheels optional

Auxiliary top auger

Type Optional hydraulic drive

Dimensions

Platform length 11.1 m
36.3 ft
Overall operating depth With crop dividers 2.6 m
8.7 ft
Transport width, field position 11.1 m
36.3 ft
Transport width on wheel, less dividers 2.5 m
8.1 ft
Transport length, hitch extended 13.9 m
45.6 ft

Weight

Approximate weight (base platform with reel) 2,134-2,588 kg
4,700-5,700 lb

Center opening / crop delivery

Center opening width between belts 1,720-1,950 mm
67.1-76.7 in.
Deck shift / double windrow capability (manual / hydraulic / not available) Manual standard
Hydraulic optional

Gauge wheels and transportation

Gauge wheels Optional
Integrated slow speed transport system Optional includes dual gauge wheels
