John Deere 735D

Double tap to zoom



  • Two available sizes for a 700D factory-installed center feed drum improves feeding of crop into the combine feederhouse
  • Takes one person a few minutes to convert draper from field to transport without use of tools
  • Dual-knife drive system is timed
  • Double-cut knife system produces a cleaner cut
  • Reel resume and reverse are features on the 700D Drapers


Key Specs

Cutterbar length 10.8 m
35.5 ft
Knife drive Base: dual knife
Knife speed 490 cycles/min
Pickup reel operating speeds 6-54 rpm
Draper belts speed control Hydraulic from cab


Type Rigid draper


Type Straight-line knife drive system
Length 10.8 m
35.5 ft
Knife drive Base: dual knife
Knife speed 490 cycles/min
Cutterbar tilt Base: hydraulic, maximum tilt 9 degree (angle)

Pickup reel

Number of slats Six bat poly base
Fingers Nylon
Diameter 1.067 m
3.5 ft
Height control Hydraulic
Speed control Hydraulic
Reel lift Cylinder stroke: 330 mm
13 in.
Total range: 391.5 mm
15.4 in.
Reel fore and aft Cylinder stroke: 359 mm
14.1 in.
Total range: 620 mm
24.4 in.
Reel resume Base
Reel reverse Base
Operating speeds 6-54 rpm

Draper belts

Width Side belts: 1.02 m
3.33 ft
Center belts: 1.4 m
4.583 ft
Center belt not included with SPW configuration
Clean height Cleats: 25.4 mm
1 in.
Operating speed Side belts: variable up to 223 m/min
735 fpm
Center belts: 212 m/min
695 fpm
Center belt not included with SPW configuration
Speed control Hydraulic from cab
Center belt reverse Base; Center belt not included with SPW configuration

Feed drum

Diameter 406 mm
16 in.
Feed drum not included with SPW configuration
Feed drum fingers Heavy-duty and round with breakaway notch and retainer
Diameter: 16 mm
0.625 in.
Number of fingers 18
Auger finger platform Dual chevron, retracting
Finger reach 152 mm
6 in.
Drum/auger reverse Base
Operating speed 195 rpm
Center clean out door Base

Header height sensing

Type Base: electrohydraulic
Header height sensing on the ground Base
Header height sensing off the ground Base

Auxiliary top auger

Type Optional: hydraulic drive


Platform length 11.6 m
37.9 ft
Overall operating depth 2.5 m
8.2 ft
Transport width, field position 11.4 m
37.5 ft
Transport width on wheel, less dividers 2.7 m
8.9 ft
Transport length, hitch extended 13.8 m
45.4 ft


Approximate weight Pickup reel: Combine only: 3,514 kg
7,746 lb
SPW only: 2,914 kg
6,423 lb
With transport: Combine only: 3,690 kg
8,136 lb
SPW only: 3,091 kg
6,813 kg
