John Deere H240

John Deere H240 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Utility Tractor Loaders


  • Available single-point hydraulic connection saves time
  • Hydraulics that improve cycle times and productivity
  • Integrated parking stands for easy attachment and removal
Manufacturer John Deere
Model H240 MSL on 5083E, 5093E, 5101E
Technical drawing
Technical drawing View diagram
Model 5083E, 5093E, 5101E
Front tire 320/85 R24 BKT (12.4 R24)
Rear tire 420/85 R30 BTK (16.9)
Front axle configuration ---
Wheelbase 81 in.
Pump capacity, gpm 11 gpm
Rated pressure, psi 2828 psi
Leveling configuration Mechanical Self Leveling (MSL)
Bucket used General Purpose
  1850 mm
  73 in.
Bucket weight, lb (kg) 178 kg
  392 lb
Lift capacity at full height, lb (kg) ---
Measured at pivot (U) 1219 kg
  2687 lb
Measured at 500 mm ahead of pivot (V) ---
Measured at 800 mm ahead of pivot (V) 1404 kg
  3095 lb
Lift capacity at 59 in. (1500 mm), lb (kg) ---
Measured at pivot (W) 1638 kg
  3611 lb
Measured at 500 mm ahead of pivot (X) ---
Measured at 800 mm ahead of pivot (X) 1580 kg
  3483 lb
Boom breakout force, lbf (kgf) ---
Measured at pivot (Y) 2128 kgf
  4691 lbf
Measured at 500 mm ahead of pivot (Z) ---
Measured at 800 mm ahead of pivot (Z) 1789 kgf
  3944 lbf
Bucket rollback force capacity, lbf (kgf) ---
At maximum height (VV) 1780 kgf
  3924 lbf
At 59-in. (1500-mm) lift height (XX) 3062 kgf
  6751 lbf
At ground-level line (ZZ) 3034 kgf
  6689 lbf
Dimensions ---
Maximum lift height, in. (mm) (A) 3370 mm
  133 in.
Clearance ---
At full height - bucket level, in. (mm) (B) 3175 mm
  125 in.
At full height - bucket dumped, in. (mm) (C) 2527.8 mm
  99.5 in.
Overall length (I+F), ft (m) 4.3 m
  14.3 ft
Overall height in carry position, ft (m) (J) ---
Digging depth, in. (mm) (H) 46 mm
  1.8 in.
Reach ---
At maximum height, in. (mm) (D) 726.6 mm
  28.6 in.
At ground level - bucket level, in. (mm) (F) 2152 mm
  85 in.
Bucket angle ---
Dump angle, degrees (E) -56.7 degree (angle)
Rollback angle, degrees (G) 43 degree (angle)
Dump angle, ground -107 degree (angle)
Cycle times ---
Loader raise, seconds 3.3 seconds
Loader lower, seconds 2.2 seconds
Bucket dump, seconds 2.6 seconds
Bucket rollback, seconds 2.6 seconds
