John Deere H380

John Deere H380 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Row-Crop Tractor Loaders



  • Superior strength and visibility
  • For heavy-duty chores
  • Parking stands are integrated on the loader
Manufacturer John Deere
Model H380 Loader on 6210R Tractor
Technical drawing
Technical drawing View diagram
Tractor
Model 6210R
Front tire 540/65R34
Rear tire 710/70R42
Front axle configuration ---
Wheelbase 2800 mm
  110 in.
Pump capacity, gpm 44 gpm
Rated pressure, psi 2900 psi
Loader
Leveling configuration ---
Bucket used 2450 Heavy-Duty Grapple
Bucket weight, lb (kg) 375 kg
  825 lb
Lift capacity at full height, lb (kg) ---
Measured at pivot (U) 1948 kg
  4286 lb
Measured at 500 mm ahead of pivot (V) ---
Measured at 800 mm ahead of pivot (V) 2131 kg
  4688 lb
Lift capacity at 59 in. (1500 mm), lb (kg) ---
Measured at pivot (W) 2936 kg
  6459 lb
Measured at 500 mm ahead of pivot (X) ---
Measured at 800 mm ahead of pivot (X) 2793 kg
  6145 lb
Boom breakout force, lbf (kgf) ---
Measured at pivot (Y) 3645 kg
  8019 lb
Measured at 500 mm ahead of pivot (Z) ---
Measured at 800 mm ahead of pivot (Z) 3234 kg
  7115 lb
Bucket rollback force capacity, lbf (kgf) ---
At maximum height (VV) 2568 kgf
  5650 lbf
At 59-in. (1500-mm) lift height (XX) 4902 kgf
  10784 lbf
At ground-level line (ZZ) 4800 kgf
  10560 lbf
Dimensions ---
Maximum lift height, in. (mm) (A) 4504 mm
  177 in.
Clearance ---
At full height - bucket level, in. (mm) (B) 4296 mm
  169 in.
At full height - bucket dumped, in. (mm) (C) 3447 mm
  136 in.
Overall length (I+F), ft (m) ---
Overall height in carry position, ft (m) (J) ---
Digging depth, in. (mm) (H) 148 mm
  6 in.
Reach ---
At maximum height, in. (mm) (D) 864 mm
  34 in.
At ground level - bucket level, in. (mm) (F) 2621 mm
  103 in.
Bucket angle ---
Dump angle, degrees (E) 68 degree (angle)
Rollback angle, degrees (G) 45 degree (angle)
Dump angle, ground 90 degree (angle)
Cycle times ---
Loader raise, seconds 2.8 seconds
Loader lower, seconds 1.8 seconds
Bucket dump, seconds 1.2 seconds
Bucket rollback, seconds 1.2 seconds
