John Deere H180

John Deere H180 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Compact Utility Tractor Loaders



  • Compatible with 4R Series Tractors and older 4 Series Tractors of similar size
  • Quik-Park™ loader mounting system for fast, easy attachment and removal
  • Quik-Change™ attachment carrier makes switching from chore to chore a snap
  • Optional skid steer attachment carrier
Manufacturer John Deere
Model H180 MSL on 4044R, 4049R, 4052R, 4066R Tractors
Technical drawing
Technical drawing  View diagram
Tractor
Model  4044R, 4049R, 4052R, 4066R
Front tire  25x8-16 6PR R1 T1
Rear tire  13.8-28 4PR R1 T1
Front axle configuration  ---
Wheelbase  1846 mm
   73 in.
Pump capacity, gpm  60.2 L/min
   15.9 gpm
Rated pressure, psi  17.2 MPa
   2499 psi
Loader
Leveling configuration  Mechanical Self-Leveling
Bucket used  Material - 73 in.
Bucket weight, lb (kg)  146 kg
   321 lb
Lift capacity at full height, lb (kg)  ---
Measured at pivot (U)  1006 kg
   2213 lb
Measured at 500 mm ahead of pivot (V)  1010 kg
   2222 lb
Measured at 800 mm ahead of pivot (V)  ---
Lift capacity at 59 in. (1500 mm), lb (kg)  ---
Measured at pivot (W)  1263 kg
   2779 lb
Measured at 500 mm ahead of pivot (X)  1201 kg
   2642 lb
Measured at 800 mm ahead of pivot (X)  ---
Boom breakout force, lbf (kgf)  ---
Measured at pivot (Y)  1743.7 kgf
   3835 lbf
Measured at 500 mm ahead of pivot (Z)  1517 kgf
   3337 lbf
Measured at 800 mm ahead of pivot (Z)  ---
Bucket rollback force capacity, lbf (kgf)  ---
At maximum height (VV)  1542 kgf
   3480 lbf
At 59-in. (1500-mm) lift height (XX)  2249 kgf
   4948 lbf
At ground-level line (ZZ)  2101 kgf
   4622 lbf
Dimensions  ---
Maximum lift height, in. (mm) (A)  2796 mm
   110 in.
Clearance  ---
At full height - bucket level, in. (mm) (B)  2590 mm
   102 in.
At full height - bucket dumped, in. (mm) (C)  2178 mm
   86 in.
Overall length (I+F), ft (m)  3.54 m
   11.7 ft
Overall height in carry position, ft (m) (J)  1.53 m
   5 ft
Digging depth, in. (mm) (H)  -122 mm
   -5 in.
Reach  ---
At maximum height, in. (mm) (D)  755 mm
   30 in.
At ground level - bucket level, in. (mm) (F)  1703 mm
   67 in.
Bucket angle  ---
Dump angle, degrees (E)  46.6 degree (angle)
Rollback angle, degrees (G)  38.4 degree (angle)
Dump angle, ground  129.54 degree (angle)
Cycle times  ---
Loader raise, seconds  2.41 seconds
Loader lower, seconds  1.62 seconds
Bucket dump, seconds  2.46 seconds
Bucket rollback, seconds  1.65 seconds
Date collected  ---
