John Deere H165

John Deere H165 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Compact Utility Tractor Loaders



  • Compatible with 3R Series Tractors
  • Quik-Park™ mounting system for efficient attachment and removal
  • Quik-Change attachment carrier makes it easier and faster to move from chore to chore
  • 1,122 pounds (509 kg) lift capacity
Manufacturer John Deere
Model H165 on 3203 Tractor
Technical drawing
Technical drawing  View diagram
Tractor
Model  3203
Front tire  25X8.50-14 6PR R4
Rear tire  15.00-19.5 6PR R4
Front axle configuration  ---
Wheelbase  1727 mm
   68 in.
Pump capacity, gpm  8.5 gpm
Rated pressure, psi  2500 psi
Loader
Leveling configuration  ---
Bucket used  ---
Bucket weight, lb (kg)  93.8 kg
   206.8 lb
Lift capacity at full height, lb (kg)  ---
Measured at pivot (U)  741 kgf
   1633 lbf
Measured at 500 mm ahead of pivot (V)  519 kgf
   1144 lbf
Measured at 800 mm ahead of pivot (V)  ---
Lift capacity at 59 in. (1500 mm), lb (kg)  ---
Measured at pivot (W)  971 kgf
   2141 lbf
Measured at 500 mm ahead of pivot (X)  752 kgf
   1658 lbf
Measured at 800 mm ahead of pivot (X)  ---
Boom breakout force, lbf (kgf)  ---
Measured at pivot (Y)  1508 kgf
   3325 lbf
Measured at 500 mm ahead of pivot (Z)  1095 kgf
   2414 lbf
Measured at 800 mm ahead of pivot (Z)  ---
Bucket rollback force capacity, lbf (kgf)  ---
At maximum height (VV)  825 kgf
   1819 lbf
At 59-in. (1500-mm) lift height (XX)  1372 kgf
   3025 lbf
At ground-level line (ZZ)  1440 kgf
   3175 lbf
Dimensions  ---
Maximum lift height, in. (mm) (A)  2593 mm
   102 in.
Clearance  ---
At full height - bucket level, in. (mm) (B)  2388 mm
   94 in.
At full height - bucket dumped, in. (mm) (C)  1993 mm
   78 in.
Overall length (I+F), ft (m)  3.7 m
   12 ft
Overall height in carry position, ft (m) (J)  ---
Digging depth, in. (mm) (H)  133 mm
   5 in.
Reach  ---
At maximum height, in. (mm) (D)  390 mm
   15 in.
At ground level - bucket level, in. (mm) (F)  1349 mm
   53 in.
Bucket angle  ---
Dump angle, degrees (E)  44 degree (angle)
Rollback angle, degrees (G)  31 degree (angle)
Dump angle, ground  ---
Cycle times  ---
Loader raise, seconds  3.57 seconds
Loader lower, seconds  2.11 seconds
Bucket dump, seconds  3.64 seconds
Bucket rollback, seconds  2.15 seconds
Date collected  ---
