John Deere H130

John Deere H130 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Compact Utility Tractor Loaders



  • Compatible with the 2025R and 2032R
  • Quik-Park™ loader mounting system
  • Built to improve visibility and stand up to years of use
  • Up to 717 pounds (326 kg) of lift capacity
Manufacturer John Deere
Model H130 NSL on 2025R Tractor
Technical drawing
Technical drawing  View diagram
Tractor
Model  2025R
Front tire  23X8.50-12 6PR R4
Rear tire  12-16.5 6PR R4
Front axle configuration  ---
Wheelbase  1600 mm
   63.0 in.
Pump capacity, gpm  12.7 L/min
   3.35 gpm
Rated pressure, psi  166.9 bar
   2421 psi
Loader
Leveling configuration  Non-Self Leveling
Bucket used  1250 pin-on mm
   49 pin-on in.
Bucket weight, lb (kg)  70.2 kg
   154.4 lb
Lift capacity at full height, lb (kg)  ---
Measured at pivot (U)  465 kg
   1023 lb
Measured at 500 mm ahead of pivot (V)  325 kg
   715 lb
Measured at 800 mm ahead of pivot (V)  ---
Lift capacity at 59 in. (1500 mm), lb (kg)  ---
Measured at pivot (W)  567 kg
   1247 lb
Measured at 500 mm ahead of pivot (X)  416 kg
   915 lb
Measured at 800 mm ahead of pivot (X)  ---
Boom breakout force, lbf (kgf)  ---
Measured at pivot (Y)  1140 kg
   2508 lb
Measured at 500 mm ahead of pivot (Z)  734 kg
   1615 lb
Measured at 800 mm ahead of pivot (Z)  ---
Bucket rollback force capacity, lbf (kgf)  ---
At maximum height (VV)  749 kgf
   1648 lbf
At 59-in. (1500-mm) lift height (XX)  931 kgf
   2048 lbf
At ground-level line (ZZ)  785 kgf
   1727 lbf
Dimensions  ---
Maximum lift height, in. (mm) (A)  1999 mm
   78.7 in.
Clearance  ---
At full height - bucket level, in. (mm) (B)  1838 mm
   72.4 in.
At full height - bucket dumped, in. (mm) (C)  1570 mm
   61.8 in.
Overall length (I+F), ft (m)  2.8 m
   9.3 ft
Overall height in carry position, ft (m) (J)  1.2 m
   3.9 ft
Digging depth, in. (mm) (H)  93 mm
   3.7 in.
Reach  ---
At maximum height, in. (mm) (D)  625 mm
   24.6 in.
At ground level - bucket level, in. (mm) (F)  1225 mm
   48.2 in.
Bucket angle  ---
Dump angle, degrees (E)  38 degree (angle)
Rollback angle, degrees (G)  24.5 degree (angle)
Dump angle, ground  118 degree (angle)
Cycle times  ---
Loader raise, seconds  4.73 seconds
Loader lower, seconds  2.88 seconds
Bucket dump, seconds  4.73 (without regen)/1.85 (with regen) seconds
Bucket rollback, seconds  2.88 seconds
Date collected  ---
