John Deere D170

John Deere D170 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Compact Utility Tractor Loaders



  • Compatible with 4M and 4R Series Tractors
  • Rigid mounted with parking kit available
  • Easy maintenance points keeps you on the job
  • 1,760 pounds (800 kg) lift capacity
Manufacturer John Deere
Model D170 on 4M and 4R OOS
Technical drawing
Technical drawing  View diagram
Tractor
Model  4044M, 4049M, 4052M, 4066M and OOS: 4044R, 4049R, 4052R, 4066R
Front tire  25x10-16.5 4PR R4
Rear tire  16.9-24 4PR
Front axle configuration  ---
Wheelbase  73 in.
   1850 mm
Pump capacity, gpm  10.2 gpm
Rated pressure, psi  2500 psi
Loader
Leveling configuration  ---
Bucket used  Materials
Bucket weight, lb (kg)  238 lb
   108 kg
Lift capacity at full height, lb (kg)  ---
Measured at pivot (U)  2391 lb
   1087 kg
Measured at 500 mm ahead of pivot (V)  1760 lb
   800 kg
Measured at 800 mm ahead of pivot (V)  ---
Lift capacity at 59 in. (1500 mm), lb (kg)  ---
Measured at pivot (W)  2875 lb
   1307 kg
Measured at 500 mm ahead of pivot (X)  2295 lb
   1043 kg
Measured at 800 mm ahead of pivot (X)  ---
Boom breakout force, lbf (kgf)  ---
Measured at pivot (Y)  3853 lbf
   1743.7 kgf
Measured at 500 mm ahead of pivot (Z)  2902 lbf
   1315.4 kgf
Measured at 800 mm ahead of pivot (Z)  ---
Bucket rollback force capacity, lbf (kgf)  ---
At maximum height (VV)  4112 lbf
   1866.1 kgf
At 59-in. (1500-mm) lift height (XX)  5191 lbf
   2355.1 kgf
At ground-level line (ZZ)  3487 lbf
   1580.6 kgf
Dimensions  ---
Maximum lift height, in. (mm) (A)  112.1 in.
   2850 mm
Clearance  ---
At full height - bucket level, in. (mm) (B)  104.1 in.
   2646 mm
At full height - bucket dumped, in. (mm) (C)  90.4 in.
   2298 mm
Overall length (I+F), ft (m)  11.5 ft
   3.522 m
Overall height in carry position, ft (m) (J)  4.94 ft
   1.5 m
Digging depth, in. (mm) (H)  -5.7 in.
   -146 mm
Reach  ---
At maximum height, in. (mm) (D)  27.7 in.
   705 mm
At ground level - bucket level, in. (mm) (F)  65.8 in.
   1672 mm
Bucket angle  ---
Dump angle, degrees (E)  42 degree (angle)
Rollback angle, degrees (G)  28.6 degree (angle)
Dump angle, ground  128.2 degree (angle)
Cycle times  ---
Loader raise, seconds  4.26 seconds
Loader lower, seconds  3.13 seconds
Bucket dump, seconds  3.14 seconds
Bucket rollback, seconds  2.42 seconds
Date collected  ---
