John Deere D160

John Deere D160 for sale at LandPro Equipment; NY, OH & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Niagara Falls, Oakfield, Savannah, Springville, NY, and East Palestine, OH, and Centre Hall, Edinboro, Fairmount City, Halifax, Harrisburg, Mifflintown, Stoneboro, and Watsontown, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

Compact Utility Tractor Loaders



  • Compatible with the 3032E and 3038E
  • Rigid mounted with parking kit available
  • Easy maintenance for increased uptime
  • 977 pounds (444 kg) of lift capacity
Manufacturer John Deere
Model D160 on 3032E and 3038E Tractors
Technical drawing
Technical drawing  View diagram
Tractor
Model  3032E, 3038E
Front tire  25x8.50-14 4PR R4
Rear tire  15.00-19.5 4PR
Front axle configuration  ---
Wheelbase  60 in.
   1525 mm
Pump capacity, gpm  5.3 gpm
Rated pressure, psi  2495 psi
Loader
Leveling configuration  ---
Bucket used  Materials
Bucket weight, lb (kg)  93 kg
   205 lb
Lift capacity at full height, lb (kg)  ---
Measured at pivot (U)  1186 lb
   539 kg
Measured at 500 mm ahead of pivot (V)  845 lb
   384 kg
Measured at 800 mm ahead of pivot (V)  ---
Lift capacity at 59 in. (1500 mm), lb (kg)  ---
Measured at pivot (W)  1294 lb
   588 kg
Measured at 500 mm ahead of pivot (X)  977 lb
   444 kg
Measured at 800 mm ahead of pivot (X)  ---
Boom breakout force, lbf (kgf)  ---
Measured at pivot (Y)  1704 lbf
   760 kgf
Measured at 500 mm ahead of pivot (Z)  1204 lbf
   537 kgf
Measured at 800 mm ahead of pivot (Z)  ---
Bucket rollback force capacity, lbf (kgf)  ---
At maximum height (VV)  1433 lbf
   639 kgf
At 59-in. (1500-mm) lift height (XX)  1814 lbf
   809 kgf
At ground-level line (ZZ)  1422 lbf
   634 kgf
Dimensions  ---
Maximum lift height, in. (mm) (A)  84 in.
   2140 mm
Clearance  ---
At full height - bucket level, in. (mm) (B)  78 in.
   1979 mm
At full height - bucket dumped, in. (mm) (C)  63 in.
   1596 mm
Overall length (I+F), ft (m)  9.5 ft
   2.9 m
Overall height in carry position, ft (m) (J)  5 ft
   0.15 m
Digging depth, in. (mm) (H)  5 in.
   131 mm
Reach  ---
At maximum height, in. (mm) (D)  24 in.
   603 mm
At ground level - bucket level, in. (mm) (F)  54 in.
   1369 mm
Bucket angle  ---
Dump angle, degrees (E)  43.8 degree (angle)
Rollback angle, degrees (G)  31.4 degree (angle)
Dump angle, ground  122 degree (angle)
Cycle times  ---
Loader raise, seconds  3.31 seconds
Loader lower, seconds  2.75 seconds
Bucket dump, seconds  1.75 seconds
Bucket rollback, seconds  1.88 seconds
Date collected  ---
