John Deere 400E

Double tap to zoom



Features

  • End-of-pin lubrication means easy maintenance
  • Parking stand kit

Specifications

Key Specs

Maximum lift height (A) 2850 mm
112.1 in.
Lift capacity at full height Measured at pivot (U)
1087 kg
2396 lb
Measured at 500 mm ahead of pivot (V)
800 kg
1764 lb
Boom breakout force Measured at pivot (Y)
1743.7 kg
3853 lb
Measured at 500 mm ahead of pivot (Z)
1315.4 kgf
2902 lbf
Bucket rollback force capacity At ground-level line (ZZ)
3485 lb
1580 kg
Clearance at full height - bucket dumped (C) 2298 mm
90.4 in.
Dump angle, degrees (E) 42 degree (angle)
Rollback angle, degrees (G) 28.6 degree (angle)

Tractor

Model 4044M, 4049M, 4052M, 4066M and OOS: 4044R, 4049R, 4052R, 4066R
Front tire 25x10-16.5 4PR R4
Rear tire 16.9-24 4PR
Wheelbase 1850 mm
73 in.
Pump capacity 10.2 gpm
Rated pressure 2500 psi

Loader

Base weight 150.99 kg
Bucket used Materials
Bucket weight 108 kg
238 lb
Lift capacity at full height Measured at pivot (U)
1087 kg
2396 lb
Measured at 500 mm ahead of pivot (V)
800 kg
1764 lb
Lift capacity at 59 in. (1500 mm) Measured at pivot (W)
1307 kg
2881 lb
Measured at 500 mm ahead of pivot (X)
1043 kg
2299 lb
Boom breakout force Measured at pivot (Y)
1743.7 kg
3853 lb
Measured at 500 mm ahead of pivot (Z)
1315.4 kg
2902 lb
Bucket rollback force capacity At maximum height (VV)
1866.1 kg
4112 lb
At 59-in. (1500-mm) lift height (XX)
2355.1 kg
5191 lb
At ground-level line (ZZ)
3487 kg
1580.6 lb
Dimensions Maximum lift height (A)
2850 mm
112.1 in.
At full height - bucket level(B)
2646 mm
104.1 in.
At full height - bucket dumped (C)
2298 mm
90.4 in.
Overall length (I+F), ft (m) 3.522 m
11.5 ft
Overall height in carry position (J) 1.5 m
4.94 ft
Digging depth (H) -146 mm
5.7 in.
Reach At maximum height (D)
705 mm
27.7 in.
At ground level - bucket level (F)
1672 mm
65.8 in.
Bucket angle Dump angle, degrees (E)
42 degree (angle)
Rollback angle, degrees (G)
28.6 degree (angle)
Dump angle, ground
128.2 degree (angle)
Cycle times Loader raise, seconds
4.26 seconds
Loader lower, seconds
3.13 seconds
Bucket dump, seconds
3.14 seconds
Bucket rollback, seconds
2.42 seconds
