Advanced technology for consistent power and performance
The EG4000 uses Honda's exclusive DAVR (Digital Automatic Voltage Regulator). The DAVR is designed to hold the voltage stability within a +/- 1% range during operation. This provides more consistent power.
Powerful Honda commercial OHV engine
Legendary Honda commercial-grade OHV engines are reliable, easy-to-start and incredibly rugged.
120/240V Selector switch - More usable power, more flexibility
Choose between using both 120 and 240 Volts, or 120 Volts only. This allows for the total generator output to be available through any of the 120 volt outlets, limited only by the capacity of the individual outlet. This enables you to power units with larger wattage requirements.
Runs 15.7 hours @ 50% load (6.3 gal.)
Keeps you working, all day long.
Protected by Honda Oil Alert®
Protects the generator by shutting the engine off when low oil is detected.
Tough one-piece welded frame
Helps protect the generator.
The EG4000 offers 2 duplex outlets with GFCI protection.
USDA-qualified spark arrestor/muffler
Electronic circuit breakers
Protects the generator from being overloaded.
|AC Output||120/240V 4000W max. (33.3/16.7A) / 3500W rated (29.2/14.6A))|
|Receptacles||20A 125V GFCI Duplex (2), 30A 125V Locking Plug, 20A 125/250V Locking Plug|
|Starting System||Recoil Only|
|Fuel Tank Capacity||6.3 Gallons|
|Run Time per Tankful||9.4 hrs. @rated load, 15.7hrs.@ 1/2 load|
|Dimensions (L x W x H)||26.8" x 20.9" x 22.5"|
|Noise Level||67 dB(A) @ rated load; 66 dB(A) @ 50% load|
|Dry Weight||148 lb.|
