CO-MINDER: Advanced Carbon Monoxide Detection System
CO-MINDER™ continuously monitors carbon monoxide (CO) levels. It automatically shuts down the generator before detected CO levels near the generator become dangerously high.
Advanced technology for consistent power and performance
The EB10000 uses Honda's exclusive DAVR (Digital Automatic Voltage Regulator). The DAVR is designed to hold the voltage stability within a +/- 1% range during operation. This provides more consistent power.
Powerful Honda GX630 commercial engine
The Honda V-Twin engine offers more power, reliability, greater fuel economy and reduced emissions in a more compact package.
Compact shape and unique design for easy installations
The EB10000 has a compact, slim design that can be easily installed on the job site. A centralized exhaust mechanism creates a unique "hot" zone for exhaust and "cool" zone for operation and passage. This design is especially helpful when using multiple units, as they can be easily positioned so as not to impact each others' cooling ventilation.
Quietest in its class!
The Honda EB10000 generator operates at a quiet noise level—73 decibels at 7 meters (equivalent to the noise of a vacuum cleaner). This low noise level is achieved through a large muffler that includes a punching pipe, a perforated mechanism that allows for the smooth release of exhaust gas.
7 outlets for easy connection of multiple tools
The control panel is positioned on the narrow side of the generator for convenient, easy access to all outlets.
i-Monitor LCD readout for performance monitoring and service diagnosis
i-Monitor™ provides information on hours of operation, generator output voltage, and battery voltage, as well as diagnostics for convenient dealer servicing.
Hanger kit/lifting eye standard
Easy folding handles
Wide, positive lock folding handles offer convenient transport and storage and a more compact unit.
Two wheel kit for easy transporting
The sturdy wheel kit makes the EB10000 easier to transport, even over rough terrain.
Best in class fuel efficency
The EB10000 runs an impressive 7.2 hours at half load and 4.6 hours at full load.
Fuel gauge standard
All circuits GFCI protected
The EB10000 offers neutral bond and full generator GFCI (Ground Fault Circuit Protection) on all outlets.
OSHA Worksite Compliant
The EB4000 was designed to meet OSHA requirements, making it ideal for worksite applications.
Tough one-piece welded frame
Helps protect the generator.
Protected by Honda Oil Alert®
Protects the generator by shutting the engine off when low oil is detected.
USDA-qualified spark arrestor/muffler
Electronic circuit breakers
Protects the generator from being overloaded.
Designed for easy maintenance
The EB10000 is designed with an easy-to-remove air cleaner and an oil gauge located near the oil filler cap – all elements that allow for ease of maintenance.
One-touch, removable plastic top cover
Allows for easy battery access and maintenance.
Reinforced standing legs
Meets OSHA, LA-ETL, and ANSI regulations
|AC Output||120/240V 10000W max. (83.8/41.6A) 9000W rated (75/37.5A)|
|Receptacles||20A 125V GFCI Duplex (2), 30A 125V Locking Plug, 30A 125/250V Locking Plug, 50A 125/250V Locking Plug|
|Fuel Tank Capacity||8.19 gal.|
|Run Time per Tankful||5.4 hrs @ rated load, 7.9 hrs @1/2 load|
|Dimensions (L x W x H)||41.0" x 27.7" x 35.1" including hanging hook & with handlebars folded|
|Noise Level||73 dB(A) @ rated load, 71 dB(A) @ 50% load|
|Dry Weight||403 lbs|
