John Deere 512 NSL

John Deere 512 NSL for sale at LandPro Equipment; NY & PA. Serving your new and used equipment needs from Alexander, Avon, Brockport, Clymer, Falconer, Hall, Macedon, Oakfield, Savannah, Springville, NY, and Edinboro, PA.

Would you like more information from LandPro Equipment? Request A Quote Here

5 Family Tractors



Changing attachments

The John Deere quick-change attachment carrier allows one person to quickly change attachments without the use of tools.

Parking stands and couplers

For parking the 512 Loader.

Boom, mast, and cylinders

The 512 Loader boom is made with tapered rectangular boom sections. The upper boom section overlaps the lower boom section to provide strength and durability to the loader structure without the use of an added knee plate

Loader configuration

The 512 Loader is configured for both Final Tier 4 (FT4) 3-cylinder two-wheel drive (2WD) 5E Tractors and older non FT4 2WD tractors. The FT4 tractors require a wider boom.

Bucket level indicator for 512 Loader

An optional bucket level indicator is available to enable the operator to determine the bucket position at ground and adjust as required.

Parking stands and couplers

For parking the 512 Loader.

512 Non-Parking Loader

The 512 Loader is designed for operators who do not require the loader to be removed for use of the tractor for other applications where the loader is not required. The normal mast and mounting frame components have been combined into one component, the mounting frame, which is solid-mounted to the tractor chassis.

For those instances where the loader needs to be removed, the loader boom can be removed from the mounting frame by removing the boom cylinder pins and the boom pins provided the boom is supported in some manner. Parking stands and hydraulic hose couplers are available as an option to assist in this process.

Hydraulic hose and fittings

The 512, 522, and 542 Loaders use the same two-wire braid, high-pressure hydraulic hose found on larger loaders. This provides added reliability and longer life.

Nitro-carbonized (nitrite or black) cylinder rods on 512 Loader

The hydraulic cylinders for the 512 Loader incorporate the nitrite (black) cylinder rods for superior corrosion resistance versus a simple chrome-plated cylinder rod, which many of the competitors in the economical loader market segment utilize.

Quick-change attachment carrier

The John Deere quick-change attachment carrier allows one person to quickly change attachments without the use of tools. Simply roll the attachment back slightly, remove the retaining pins, and then roll the attachment forward and lower to the ground.

Competitive attachment adapter brackets - 1 pair

Allows using non-John Deere, specialized attachments with 512, 522, 542, 553, and 563 Loaders.

  • Quick-change feature is retained

Hood guard for 5103, 5203, 5303, 5105, 5205, 5200, 5210, 5220, 5300, 5310, 5310N, 5320, 5320N, 5400, 5400N, and 5403 Tractors

The hood guard is highly recommended for 5103, 5203, 5303, 5105, 5205, 5200, 5210, 5220, 5300, 5310, 5310N, 5320, 5320N, 5400, 5400N, and 5403 Tractors. The basic function is to:

  • Help protect the tractor grille and hood from falling debris or stationary objects such as a wagon or mixer
  • Allow for lighting at night
  • Can be used with or without the tractor front weight bracket but not with the actual front weights while using the loader (this would overload the front axle)
  • Cannot be used with a front hitch

It is highly recommended to purchase a front weight bracket when using a loader. The hood guard is designed to be slightly rearward of the front weight. This is so the front weight is the first point of contact against lower stationary objects.

Brush guard

The brush guard is designed for operators who require added protection against debris from damaging the expensive-to-replace front grille or lights.

Hood guard for 5045D, 5055D, 5045E, 5055E, 5065E, and 5075E two-wheel drive (2WD) and mechanical front-wheel drive (MFWD) Tractors

The hood guard is highly recommended for the 5D and 5E Tractor Series. The basic function is to:

  • Help protect the tractor grille and hood from falling debris or stationary objects such as a wagon or mixer
  • Allow for lighting at night

Hood guard for 3-Cylinder 5E Tractors

The basic functions of the hood guard are:

  • Help protect the tractor grille and hood from falling debris or stationary objects such as a wagon or mixer while loading
  • Allow for lighting at night
  • Can be used with or without the tractor front weight bracket but not with the actual front weights while using the loader
  • Cannot be used with a front hitch

66-in. (1680-mm) general purpose bucket

  • The GP buckets have replaced the 61-in. and 73-in. materials buckets
  • Compatible with digging teeth and replaceable cutting edge
  • The 66 in. GP bucket will cover wheel tracks where the 61 in. would not
  • Not compatible with grapples
  • The GP buckets are more durable than materials buckets with full length side cutting edges, additional bottom skid plates, and a double reinforced top section
  • Holes are drilled in the cutting edge allowing easy attaching of a reversible and replaceable cutting edge

73-in. (1850-mm) general purpose bucket

  • The 73-in. GP buckets have replaced the 73-in. materials and heavy-duty buckets
  • Not compatible with grapples
  • The GP buckets are more durable than materials buckets with full-length side cutting edges, additional bottom skid plates, and a double reinforced top section
  • Holes are drilled in the cutting edge allowing easy attaching of a reversible and replaceable cutting edge
Model 5005/5105/5205
Front tire 7.5-16 6 PR R1
Rear tire 13.6-28 6 PR R1
Front axle configuration ---
Wheelbase 1950 mm76.8 in.
Pump capacity, gpm 10.9 gpm
Rated pressure, psi 2755 psi
Leveling configuration ---
Bucket used 1850 mm73 in.
Bucket weight, lb (kg) 159 kg351 lb
Lift capacity at full height, lb (kg) ---
Measured at pivot (U) 1000 kg2200 lb
Measured at 500 mm ahead of pivot (V) ---
Measured at 800 mm ahead of pivot (V) 682 kg1500 lb
Lift capacity at 59 in. (1500 mm), lb (kg) ---
Measured at pivot (W) 1380 kg3043 lb
Measured at 500 mm ahead of pivot (X) ---
Measured at 800 mm ahead of pivot (X) 980 kg2161 lb
Boom breakout force, lbf (kgf) ---
Measured at pivot (Y) 2019 kg4451 lb
Measured at 500 mm ahead of pivot (Z) ---
Measured at 800 mm ahead of pivot (Z) 1335 kg2944 lb
Bucket rollback force capacity, lbf (kgf) ---
At maximum height (VV) 979 kg2158 lb
At 59-in. (1500-mm) lift height (XX) ---
At ground-level line (ZZ) 1410 kg3109 lb
Dimensions ---
Maximum lift height, in. (mm) (A) 2850 mm112 in.
Clearance ---
At full height - bucket level, in. (mm) (B) 2635 mm103.5 in.
At full height - bucket dumped, in. (mm) (C) 2635 mm103.5 in.
Overall length (I+F), ft (m) 3.66 m12 ft
Overall height in carry position, ft (m) (J) 1.43 m4.69 ft
Digging depth, in. (mm) (H) 150 mm6 in.
Reach ---
At maximum height, in. (mm) (D) 615 mm23.5 in.
At ground level - bucket level, in. (mm) (F) 1710 mm67 in.
Bucket angle ---
Dump angle, degrees (E) 43 degree (angle)
Rollback angle, degrees (G) 30 degree (angle)
Dump angle, ground ---
Cycle times ---
Loader raise, seconds ---
Loader lower, seconds ---
Bucket dump, seconds ---
Bucket rollback, seconds ---
Date collected ---
